Fully Automatic Soap Making Machine | 100-3000kg/h Capacity | Stainless Steel 304

Name: Fully Automatic Soap Making Machine 1003000kgh Capacity Stainless Steel 304
Brand: LOVO
Price: 5000 USD

Quality Fully Automatic Soap Making Machine | 100-3000kg/h Capacity | Stainless Steel 304 for sale

Brand Name : LOVO

MOQ : 1

Packaging Details : 1000X5000X1000 cm

Place of Origin : China

Payment Terms : Western Union,T/T,D/P,D/A,L/C

Delivery Time : 10-25

Model Number : 5001-10000

Price : 5000-10000

Supply Ability : 666

Contact Now

Fully Automatic Soap Making Machine with Stainless Steel 304 Components and 100-3000kg/h Capacity

Soap Making Machine Small Beauty Soap Production Line Chemical Soap Plodder Machine

We offer complete toilet and laundry bar soap production equipment lines with capacities ranging from 100kg/h to 2000kg/h. Our laundry soap production line includes mixing systems, three-roller mills, double-screw double-layer vacuum plodders, refrigeration units, vacuum strip cutting, and soap cutting machines.

Mix all materials using mixing agitators, grind soap noodles with three-roller mills, form soap bars with vacuum plodders, and cut soaps with stamping machines
Distribution boxes control all machine motors, while conveyors transport soap materials
Water pumps cool the vacuum plodders, and vacuum pumps vacuumize soap materials
Components contacting soap materials can be manufactured from stainless steel 304

Key Specifications

Machine Type	Soap Machine	Automatic Grade	Fully Automatic
Voltage	380V, 220V	Core Components	PLC, Motor, Gearbox, Pump
Warranty	1 Year	Machinery Test Report	Provided
Brand Name	LOVO	Model Number	LV600
Place of Origin	Henan, China	Weight	1000 kg
Capacity	100-3000 kg/h	Applicable Industries	Manufacturing Plant

Fully Automatic Soap Making Machine | 100-3000kg/h Capacity | Stainless Steel 304

Technical Parameters

Soap Cutting Machine

Soap bar dimensions: Length 70mm-600mm, Thickness ≤55mm, Width ≤90mm
Cutting accuracy: ±1g
Motor power: 1.2kw
Overall dimensions: 820x500x1080mm
Equipment weight: 110kg

Our electronic laundry soap cutting machine features continuous automatic cutting of soap bars from the plodder into cakes or stamping patterns. With electronic tracking system, it can cut laundry soap bars of different sizes and weights after computer setting. The mold wheels are driven by soap bar movement from the plodder, ensuring clear characters, vertical ends, smooth and neat surfaces, and easy operation.

Soap Production Line Process

Mixer

Equipped with motor and gearbox to fully stir soap flakes with various liquid and solid additives. Provides thorough and uniform stirring, completely dissolving color paste and additives into the soap base to meet different customer formula requirements.

Three-Roller Mill

Features three horizontally arranged rollers operating at varying speeds. Soap particles undergo squeezing and shearing on the roller surfaces to achieve optimal grinding effect.

Double Layer Vacuum Plodder Machine

Composed of two-stage discharge screw system. The primary stage functions as a single refiner machine to manufacture soap noodles under vacuum. At the final stage, soap noodles are compressed, squeezed, and continuously output as soap bars.

Electric Soap Cutting Machine

Size: 800x300x1000mm
Power: 6kw
Frequency: 50HZ
Voltage: 380V
Function: Cutting and printing

Detailed Specifications

Product Name	SOAP Cutting Machine
Capacity	100-2000 kg/h
Speed of Mixing Drum	20-40 r/min
Motor Power	2.6-6 KW
Warranty	1 Year

Different Models

Our Customers

Contact Us
